Vertical Openwell Submersible Pump Set

Application

Open Well Dam, River, Lake, Rain Gun, Fountains, Sprinklers, Domestic, Factories, Agriculture, Drip Irrigation,Plants Nursery, etc.

Power

3.0 HP To 60 HP

Head Range

16 Feet to 900 Feet

Discharge Range

160 L.P.M to 3600 L.P.M

Material of Construction

Bowl / Impeller : Cast Iron FG200
Stage Casting : Cast Iron FG200
Motor Casting : Cast Iron FG200
Pump Shaft : Stainless Steel 410
Roter Shaft : Stainless Steel 410
Motor Bush : LTB4
Thrust Bearing : Carbon Vs Steel

Mini Vertical Openwell Submersible Pump Set

Application

Open Well, Water tank, Fountains, Sprinklers, Domestic, Factories, Hotels, Plants Nursery, etc.

Power

1 HP To 2 HP

Head Range

12 Feet to 300 Feet

Discharge Range

45 L.P.M to 390 L.P.M

Material of Construction

Bowl / Impeller : Noryl
Pump Casting Pipe : Stainless Steel
Motor Casting : Stainless Steel
Pump Shaft : Stainless Steel 410
Roter Shaft : Stainless Steel 410
Motor Bush : LTB4
Thrust Bearing : Carbon Vs Steel

Metro Series

Special Design For High Rise Building

Application

Pumping ground water to Over head, tanks Of High rise Building, STP Plants, Fire Fighting Pumping System

Power

1 HP To 2 HP Available in Single / Three Phase
3 HP To 20 HP Available in Three Phase

Head Range

12 Feet to 440 Feet

Discharge Range

70 L.P.M to 950 L.P.M

Material of Construction

Bowl / Impeller : Stainless Steel 410
Stage Casting : Cast Iron FG200
Motor Casting : Cast Iron FG200
Pump Shaft : Stainless Steel 410
Roter Shaft : Stainless Steel 410
Motor Bush : LTB4
Thrust Bearing : Carbon

Domestic vertical open well
Submersible pumps

Suitable For Wide Voltage Operation 180 to 240 Volt(Single Phase)
350 V to 425 Volts Three Phase
Carbon VS Steel Thrust Bearing
Copper Rotor
SS Bowl & Impeller
Minimum Submergence
Suitable For Construction Site, Sump Well,Open Well,Gardening,Sprinklers,Etc.

Horizontal Open well
Submersible pumps

Material of Construction

Bowl / Impeller : Cast Iron FG200
Stage Casting : Cast Iron FG200
Motor Casting : MS
Pump Shaft : Stainless Steel 410
Roter Shaft : Stainless Steel 410
Motor Bush : LTB4
Thrust Bearing : Carbon Vs Steel

V-4

4” (100 mm ) Borewell Submersible pump set

Application

Domestic, Hotels, Agriculture, Factories, Plants, Nursery,
Drip Irrigation etc.

Power

0.5 HP To 2 HP Available in Single/three Phase
3.0 HP To 5.0 HP Available in three Phase

Head Range

16Feet to 623 Feet

Discharge Range

10 L.P.M to 390 L.P.M

Material of Construction

Bowl / Impeller : Noryl
Pump Casting Pipe : Stainless Steel
Motor Casting : Stainless Steel
Pump Shaft : Stainless Steel 410
Rotor Shaft : Stainless Steel 410
Motor Bush : LTB4
Thrust Bearing : Carbon Vs Steel

V-6

6” (150 mm ) Borewell Submersible pump set

Application

Agriculture, Factories,, Rural Water Supply, Plants Nursery, Municipal Corporation
Drip Irrigation etc.

Power

3.0 HP To 25.0 HP

Head Range

13Feet to 1150 Feet

Discharge Range

30 L.P.M to 1200 L.P.M

Material of Construction

Bowl / Impeller : Stainless Steel 410
Stage Casting : Cast Iron FG200
Motor Casting : Stainless Steel
Pump Shaft : Stainless Steel 410
Rotor Shaft : Stainless Steel 410
Motor Bush : LTB4
Thrust Bearing : Carbon Vs Steel

V-8

8” (200 mm) Borewell Submersible pump set

Application

Agriculture, Factories, Rural Water, Supply, Plants Nursery, Municipal Corporation, etc.

Power

7.5 HP To 60 HP

Head Range

22Feet to 900 Feet

Discharge Range

160 L.P.M to 2800 L.P.M

Material of Construction

Bowl / Impeller : Stainless Steel 410
Stage Casting : Cast Iron FG200
Motor Casting : Stainless Steel
Pump Shaft : Stainless Steel 410
Rotor Shaft : Stainless Steel 410
Motor Bush : LTB4
Thrust Bearing : Carbon Vs Steel
